Humminbird Transom Mount Transducers

Transom Mount Transducer
7 Pin Plug, Single/Dual Beam, 20/60 Degree, 200/83kHz with temperature

Transom Mount Transducer
7 Pin Plug, Single/Dual Beam, 20/60 Degree, 200/83kHz

Transom Mount Transducer
HD Side Imaging, Dual Beam Plus, 20/60/180 Degree, 200/83/455/800kHz with Temperature

Transom Mount Transducer
Compact Side Imaging, Dual Beam Plus, 20/60/180 Degree, 200/83/455kHz with Temperature

Transom Mount Transducer
Compact Side Imaging, Dual Beam Plus, 20/74 Degree, 200/50 kHz with Temperature for use with XD model products.

Transom Mount Transducer
Down Imaging/Dual Beam Plus, 75/45 Degree, 455/800kHz (DI) + 25/16 Degree, 200/455kHz, with Temperature

Transom Mount Transducer
EXTRA DEEP Single/Dual Beam, 16/28 Degree, 455/200 kHz, with built in temperature

Transom Mount Transducer
Digital CHIRP Dual Spectrum 2D and Digital CHIRP MEGA Down Imaging. Dual Spectrum 2D CHIRP with 25° and 42° coverage @ -10dB, 455/800/MEGA MEGA DI CHIRP with 45° and 75° @ -10dB. FOR USE WITH HELIX MEGA DI G2 PRODUCTS ONLY

Transom Mount Transducer
MEGA SI, MEGA DI, DualBeam PLUS, 20/60/86/55 degrees, 200/83/455/800 kHz and 1.2 MHz, temperature built-in.  For HELIX MEGA Side Imaging units only.

Transom Mount Transducer
Single/Dual Beam, 20/60 Degree, 200/83kHz with temperature. For Ion/Onix/Solix series units

Transom Mount Transducer
Single/Dual Beam, 20/74 Degree, 200/50kHz with temperature. For Ion/Onix/Solix series units.

Transom Mount Transducer
Down Imaging/Dual Beam Plus, 75/45 Degree, 455/800kHz (DI) + 25/16 Degree, 200/455kHz, with Temperature. For Ion/Onix/Solix series units.

Transom Mount Transducer
HD SI, HD DI, Dual Beam, 20/60/90/180 degrees, 200/83/455/800 kHz ​with Temperature. For Ion/Onix series units.

Transom Mount Transducer
HD SI, HD DI, Dual Beam, 20/60/90/180 degrees, 200/50/455/800 kHz ​with Temperature. For Ion/Onix series units.

Transom Mount Transducer
Digital CHIRP Dual Spectrum 2D and Digital CHIRP MEGA Down Imaging. Dual Spectrum 2D CHIRP with 25° and 42° coverage @ -10dB, 455/800/MEGA MEGA DI CHIRP with 45° and 75° @ -10dB. FOR USE WITH SOLIX PRODUCTS ONLY

Transom Mount Transducer
MEGA SI, MEGA DI, DualBeam PLUS, 20/60/86/55 degrees, 200/83/455/800 kHz and 1.2 MHz, temperature built-in. For SOLIX MEGA Side Imaging units only.

New for 2019

Transom Mount Transducer
Dual Spectrum CHIRP: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz Max Depth: 1200ft (365m), temperature built-in. For HELIX G2, G2N, G3 and G3N units only.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m), Down Imaging Frequencies - Max Depth: 455kHz: 440-500 kHz - 350ft (107m), MEGA DI: 1075-1150 kHz - 125ft (38m), temperature built-in. For HELIX 7 CHIRP MEGA DI GPS G3/G3N,  HELIX 8 CHIRP MEGA DI GPS G3N units only.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m), Down Imaging Frequencies - Max Depth: 455kHz: 440-500 kHz - 400ft (122m), 800kHz: 790-850 kHz - 125ft (38m), MEGA DI+: 1075-1150 kHz - 200ft (61m), temperature built-in. For HELIX 8/9/10/12 G3N Series MEGA DI+ and MEGA SI+ units only.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m),Side Imaging Frequencies - Max Range (side-to-side): 455kHz: 440-500 kHz - 800ft (146m), MEGA SI: 1075-1150 kHz - 250ft (76m), Down Imaging Frequencies - Max Depth: 455kHz: 440-500 kHz - 125ft (38m), MEGA DI: 1075-1150 kHz - 75ft (23m), temperature built-in. For HELIX 7 CHIRP MEGA SI GPS G3/G3N units only.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m), MEGA Side Imaging+ Frequencies - Max Range (side-to-side): 455kHz: 440-500 kHz - 800ft (244m), 800kHz: 790-850 kHz - 250ft (76m), MEGA SI+: 1075-1150 kHz - 400ft (122m), MEGA Down Imaging+ Frequencies - Max Depth: 455kHz: 440-500 kHz - 400ft (122m), 800kHz: 790-850 kHz - 125ft (38m), MEGA DI+: 1075-1150 kHz - 200ft (61m), temperature built-in. For HELIX 8/9/10/12 CHIRP MEGA SI+ GPS G3N.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz Max Depth: 1200ft (365m), temperature built-in. For SOLIX 10, 12, 15 – All Model.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m), Down Imaging Frequencies - Max Depth: 455kHz: 440-500 kHz - 400ft (122m), 800kHz: 790-850 kHz - 125ft (38m), MEGA DI+: 1075-1150 kHz - 200ft (61m), temperature built-in. For SOLIX 10/12/15 CHIRP MEGA DI+ GPS G2 units only.

New for 2019
Transom Mount Transducer
Dual Spectrum CHIRP Frequencies: Full: 150-220 kHz, Narrow: 180-240 kHz, Wide: 140-200 kHz, Dual Spectrum CHIRP Max Depth: 1200ft (365m), MEGA Side Imaging+ Frequencies - Max Range (side-to-side): 455kHz: 440-500 kHz - 800ft (244m), 800kHz: 790-850 kHz - 250ft (76m), MEGA SI+: 1075-1150 kHz - 400ft (122m), MEGA Down Imaging+ Frequencies - Max Depth: 455kHz: 440-500 kHz - 400ft (122m), 800kHz: 790-850 kHz - 125ft (38m), MEGA DI+: 1075-1150 kHz - 200ft (61m), temperature built-in. For SOLIX 10/12/15 CHIRP MEGA SI+ GPS G2 units only.
